产品名称９/div>
Supeltex
?M-2A Capillary Ferrule, Short Design
产品介绍９/div>
产品说明
一般描?/p>
Swage type fittings are one of the most popular connectors which are available in metal and plastic forms; they are very useful for connecting similar or dissimilar materials, like metal to glass or metal to plastic. The general swage tubing coupler has four parts namely the body, into which the tube is placed, two ferrules that is front ferrule and back ferrule and lastly a packing nut. If one is using the original nut supplied for the injector and non-MS detector end of an GC instrument, one should choose a Supeltex short design ferrule. M-2A Capillary Ferrule Conforms easily to capillary columns, ensuring an effective seal with less chance of breakage and has high reusability.
特性：
用手拧四分之一圈可紧固密封。可重用性高。不会粘连金属或玻璃、br />
材料成分９/B>DuPont VESPEL SP-21(85% 聚酰亚胺?5% 石墨)
最高温度：400ℂ/p>
法律信息
Supeltex is a registered trademark of sigma-aldrich Co. LLC
Vespel is a trademark of E. I. du Pont de Nemours and Company
基本信息
产品性质
| 特点 |
ferrule type short |
| 包装 |
pkg of 10 ea |
| manufacturer/tradename |
Agilent/HP 5062-3516 (OEM) |
| 内径 |
0.4 mm |
| 相容?/td> |
0.10-0.25 mm Column I.D. |
安全信息
| 储存分类代码 |
13 - Non Combustible Solids |
| WGK |
WGK 3 |
| 闪点(F) |
Not applicable |
| 闪点(C) |
Not applicable |
