High Capacity Gas Purifier, Starter Kit
大容量气体净化器，入门套仵�br />

产品介绍９�/div>

产品说明

一般描�?/p>

No other purifier removes both moisture and oxygen in such large quantities (35 liters of moisture, 14 liters of oxygen ).

Protects GC columns and detectors from damage caused by moisture and oxygen in the carrier gas stream, even when present up to 100 ppm levels. The clam-shell oven heats a converter tube to 580�? causing moisture and oxygen to irreversibly react with the reactant material. This chemical reaction prevents contaminants from returning to the gas stream, even when the material approaches saturation, or when the oven is cooled. Carbon monoxide and carbon dioxide are also removed.

It is recommended to install 4 ft. (1.2 m) of tubing downstream of the oven to allow heat to dissipate from the gas stream. This tubing can be coiled to reduce space.

The starter kit includes a clam-shell oven, two elements (installed), and a converter tube.

Note:Not for use with hydrogen gas.

Clam-Shell Oven:

• Length: 14¹/₂in. (36.8 cm)
• Height: 5¹/₄in. (13.3 cm)
• Depth: 6 in. (15.2 cm)
• Operating Temp.: 580ℂ�/LI>
• Power Consumption: 90 watt
• Conformity marks: CE Approved
• Mounting: Horizontally only (bench or wall) using integral bracket
• Warranty:1 year

Converter Tube:

• Length inside column oven: 10 in. (25.4 cm)
• Diameter:¹/₂in. (12.7 mm)
• Max. Inlet Pressure: 150 psi
• Max. Flow Rate: 1100 mL/min

基本信息

NACRES

SB.54

产品性质

质量水平	100
尺寸	1/8 in.

安全信息

象形国�/td>
警示用语９�/td>	Danger
危险声明	H228
预防措施声明	P210 - P240 - P241 - P280 - P370 + P378
危险分类	Flam. Sol. 1
储存分类代码	4.1B - Flammable solid hazardous materials
WGK	WGK 1
闪点(F)	Not applicable
闪点(C)	Not applicable
