产品介绍
| 订货叶/strong> |
包装规格 |
| Length (Round) |
| 538-518-11 |
100 mm |
| 459-955-29 |
200 mm |
| 464-574-66 |
500 mm |
| 654-799-66 |
1000 mm |
产品参数
| Diameter[直径] |
25.4mm |
| Length[长度] |
100 mm - 1000 mm |
| Typical Analysis(典型分析) |
| Pb |
<200 PPM |
| Mechanical Properties(机械性能) |
| Elongation at break ( % ) |
< 60.0 |
| Hardness - Brinell |
80 - 225 |
| Izod impact strength ( J m?? ) |
62.0 |
| Modulus of elasticity ( GPa ) |
90.0 - 120.0 |
| Shear strength ( MPa ) |
250 - 430 |
| Tensile strength ( MPa ) |
320.00 - 740.00 |
| Thermal Properties(热性能) |
| Coefficient of thermal expansion ( x10?? K?? ) |
17.000 @20-100ℂ/td> |
| Melting point ( C ) |
900.00 - 1050.00 |
| Thermal conductivity ( W m?? K?? ) |
50.00 - 75.00 @23ℂ/td> |
| Electrical Properties(电气特? |
| Electrical resistivity ( μOhmcm ) |
11.0-16.0 |
| Temperature coefficient ( K?? ) |
0.00060 - 0.00070 |
| Physical Properties(物理性质) |
| Density ( g cm?? ) |
8.900 |
其他参数
公差
| 直径 |
?0mm |
10% |
| 聚合?/td> |
+20% / -10% |
| 陶瓷 |
+20% / -10% |
|
| >10mm |
5% |
| 陶瓷 |
+20% / -10% |
| 聚合?/td> |
+20% / -10% |
|
| 长度 |
<100mm |
1mm |
| ?00mm |
+5% / -1% |
|
|
